Compact, Feature-Rich Delay Pedal with 6 Delay Types, Switchable Modes and 9 Programmable Presets

Product Features
  • Compact, feature-rich delay pedal lets you create totally unique sounds with 6 delay types, switchable modes and 9 programmable presets

  • 6 studio-quality digital delay types including dynamic delay, reverse and slapback

  • Easily switch between manual operation mode and a preset at any time

  • 9 user-programmable presets make it simple to recall the exact sound you need

  • Up to 2290 ms of delay time gives you plenty of room for immense tonal impact

  • Audio Tapping feature allows you to set delay tempo by strumming your guitar

  • Alternate tap tempo control keeps your delay effects right on the beat

  • 3 modulation types with level control let you create incredibly lush delay lines

  • Spillover gives you a natural delay trail decay when you change modes

  • True stereo I/O provides incredibly wide three-dimensional tones

  • 12 Volt power supply included

  • Designed and engineered in Denmark

Delay Goes SuperNova
Delay Goes SuperNova

          When you are the company that did the 2290, it’s easy to get complacent. But we just want to move forward into the new and when we saw a need in the market for a compact, yet feature-rich delay pedal, we knew exactly what to do - introduce the NOVA DELAY!

    •    6 studio quality delay types
    •    Preset- and manual mode
    •    9 user programmable presets

6 Super Sounds - Endless Possibilities
6 Super Sounds - Endless Possibilities

          NOVA DELAY houses 6 delay types and 2290 MS of delay time. Add the modulation options and you’ve got yourself a delay that came to play!

Manual or Preset
Manual or Preset

          Combining the ease of use of presets with the freedom and control, NOVA DELAY offers a manual mode plus 9 presets. You can toggle between manual mode and one of the presets at any time.

Set to Stay
Set to Stay

          NOVA DELAY features room to rock with 9 preset positions you can fill with sounds you can instantly recall.

Specification
Analog Inputs
Connectors 1/4" phone jacks w. monosense
Impedance 1 MOhm
Max. Input Level TBD dBu
A to D Conversion 24 bit, 128 x oversampling bitstream
A to D Delay TBD
Dynamic Range 105 dB typ, 20 Hz - 20 kHz
THD typ. < 92 dB (0,0025 %) @ 1 kHz
Frequency Response +0/-0.1 dB @ 48 kHz, 20 Hz to 20 kHz
Crosstalk <-95 dB, 20 Hz to 20 kHz
Analog Outputs
Connectors 1/4" phone jack, balanced
Impedance Balanced / Unbalanced 40 Ohm
Max. Output Level TBD dBu
D to A Conversion 24 bit, 128 x oversampling bitstream
D to A Delay TBD
Dynamic Range 105 dB typ, 20 Hz to 20 kHz
THD typ <-94 dB (0.002 %) @ 1 kHz, +20 dBu Output
Frequency Response +0/-0.5 dB @ 48 kHz, 20 Hz to 20 kHz
Crosstalk <-100 dB, 20 Hz to 20 kHz
EMC
Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Enviroment
Operating Temperature 32° F to 122° F (0° C to 50° C)
Storage Temperature -22° F to 167° F (-30° C to 70° C)
Humidity Max. 90 % non-condensing
General
Finish Anodized aluminum front Plated and painted steel endcaps
Dimensions 12,5 x 12,5 cm
Mains Voltage 100 to 240 VAC, 50 to 60 Hz (auto-select) AC wall adapter
Power Consumption <5 W
