Dual-Engine Signal Processor With High-Quality Reverb and Multi-Effects for Live or Studio Applications
Product Features
  • Powerful dual-effects signal processor offers advanced reverb and other effects to help you sound fantastic in both live and studio applications

  • Innovative XL Reverb technology provides improved spatial perspectives and sophisticated modulation patterns to give you an exceptionally natural and clear sound

  • Wide array of high-quality multi-effects adds impact to your live performances, including delay, chorus, flanger, gate, and more

  • Dual-engine structure lets you run two full-blown effects simultaneously and is configurable into six different routing setups, giving you the flexibility you need to achieve the perfect sound in both live and studio situations

  • XL Reverb tuning that combines early reflection patterns with new diffused fields provides realistic small room simulations

  • 200 high-grade factory presets to cover every imaginable application, and additional space to store 100 more user presets

  • Classic hall reverbs simulate very large, high-ceilinged venues to help your vocals, acoustic guitar, and piano sound great anywhere

  • Renowned TC Electronic room reverbs let you create a vast array of spaces with different sizes and surfaces, adding realism and texture to your mix

  • Grainy-sounding live reverb algorithms offer a sound reminiscent of the 1980's live reverbs, giving an extra edge to help you really cut through any PA system

  • Basic plate reverbs let you painlessly recreate the artificial reflections typically found on "old mechanical" reverbs

  • Designed and engineered in Denmark

Studio & Post production M-ONE XL
Studio & Post production M-ONE XL

M-ONE XL is a dual effects unit, perfectly designed for LIVE applications. The reverbs truly shine, but it also features lots of other pristine effects such as Compressor, Chorus, Delay, Gate, etc.

    •    TC ELECTRONIC XL Technology - Based on Our Renowned Reverb Heritage
    •    High-quality Multi Effects - Reverb, Delay, Chorus, Flanger, Compressor, Gate, etc.
    •    Flexibility - Perfect for LIVE applications as well as in the STUDIO



XL Reverb Technology
XL Reverb Technology

Do the measures - it's time to size up! The essence of M-ONE XL, the XL Technology, is based on our heritage and continual research and development of Reverb technology. XL Reverbs give you new and improved spatial perspectives, across the entire range of Reverb algorithms.

The extended range of the 'reverb size' enables extremely wide or narrow spatial imaging, independently of the decay time. By applying 'Reverb size' to both Early Reflections and the Diffused Field, M-ONE XL achieves any combination from wide spaces with short decay times to narrow rooms with long decays.

The XL Technology also stands out by applying sophisticated modulation patterns, simulating the modulation of a real room and allowing ranges of modulation from the barely audible real-room modulation to heavy chorusing and detuning reverbs, also simulating the vintage style of reverbs.

In short, you will get a natural and clear result that no other processor in this price range is able to provide.

Small Room Simulation
Small Room Simulation

Simulations of Small Rooms have been a major focus in the tuning of the XL Reverbs. The Early Reflection patterns combined with the new set of Diffused Fields, allows for realistic simulations of real rooms.

If you apply it to source material, the room simulations will bring clarity and presence to the source. With the flexibility of the XL Technology, your can tweak the reverbs from virtually transparent Ambience patterns over large Hall Reverbs to low-resolution Plates or Spring reverbs with ease.

Reverb Types
Reverb Types

M-ONE XL offers you all the great types of reverb you need for live performances or in the studio. Depending on the application, you can go for Live, Hall, Room or Plate.

Hall
Hall

These 'classic' reverbs simulate the reverberation of very large rooms with high ceilings. They have unobtrusive reflections with a density and naturalness you have only been dreaming of - until now. The Hall reverbs are particularly great-sounding for vocals, acoustic guitar and piano.

Room
Room

Our famous Room reverbs generate a vast array of room settings with different sizes and surfaces. The Room reverbs will make your music come alive by adding ultimate realism and texture to your mix.

Live
Live

The Live algorithms are the grainy type of reverbs known as the typical 1980s live reverbs. Use these reverbs whenever you need the extra edge to really 'cut through' any PA system.

Plate
Plate

The most basic-sounding reverbs in the M-ONE XL are the 'non-digital', mechanical-sounding ones, which eIiminates the need for metal plates: Create the artificial reflections typically found on 'old mechanical' reverbs! Plates 1 & 2 are particularly good for drums and vocal tracks.

Presets
Presets

M-ONE XL comes with 200 high-grade Factory Presets, covering any application imaginable. On top of that, M-ONE XL stores up to 100 of your favorite presets in the User Bank. When you are satisfied with your preset, just hit the STORE key to save. It is so simple, that you almost forget you are actually making presets!

How to...
How to...

M-ONE XL will handle all of your reverb needs with ease, and the range of applications is comprehensive, but we have gathered a few tips for three common situations below.

Lead Vocals
Lead Vocals

Dominating vocals are often supported by a well-tuned Hall and maybe even some delays. However, combining these two effects in the perfect mix can be a bit of a challenge.

The fact that Delay repeats continue to repeat the original dry source, even after the Reverb has decayed, makes the delay stand out as a separate effect.

Using the M-ONE XL 'Parallel/Serial' routing allows you to use both Delay, with the accurate tap control, and high-density Reverbs with independent inputs and simultaneously feed the Delay repeats into the Reverb, allowing a greater integration of the two effects.

Ambient Vocals
Ambient Vocals

Getting the lead vocal to sound both crisp and present in a live mix is not always as easy as it sounds.

If you merely turn up the volume, keeping a neutral frequency response will make the vocal 'float' on top of the music, which is not very flattering to the vocals.

Instead, try to use the 'Ambience' Reverb of the M-ONE XL. The high-density Early Reflections and short decays will add sufficient brightness and shine to the vocal without compromising the frequency response.

Drums
Drums

Making a drum kit in general, or a snare drum in particular, stand out using reverbs has been common in Pop/Rock for many years. In the studio, where listening conditions are perfect, you have a number of choices. Achieving the same effect in a Live situation is quite a different story.

High-density reverbs tend to disappear in a PA system, so try to use the ‘Live’ reverb of M-ONE XL. It will give you exactly the level of graininess necessary to achieve this particular effect.

The ‘Live’ Reverb works extremely well for short and snappy snare reverbs, as well as big ballad 3.0 second Tom reverbs.

Specification
Digital Inpits and Outputs
Connectors

RCA Phono (S/PDIF)

Formats

S/PDIF (24 bit), EIAJ CP-340, IEC 958

Output Dither

HPF/TPDF dither 24/20/16/8 bit

Sample Rates

44.1 kHz, 48 kHz

Processing Delay

0.1 ms @ 48 kHz

Frequency Response DIO

DC to 23.9 kHz ± 0.01 dB @ 48 kHz

Analog Inputs
Connectors

XLR, balanced

Impedance, Bal / Unbal

21 kOhm / 13 kOhm

Max. Input Level

+24 dBu

Min. Input Level for 0 dBFS

0 dBu

Sensitivity @ 12 dB headroom

-12 dBu to +12 dBu

A to D Conversion

24 bit, 128 x oversampling bitstream

A to D Delay

0.65 ms / 0.70 ms @ 48 kHz / 44.1 kHz

Dynamic Range

100 dB typ, 20 Hz - 20 kHz

THD

typ < 92 dB (0,0025 %) @ 1 kHz

Frequency Response

+0/-0.1 dB @ 48 kHz, 20 Hz to 20 kHz

Crosstalk

<-95 dB, 20 Hz to 20 kHz

Analog Outputs
Connectors

XLR, balanced

Impedance Balanced / Unbalanced

40 Ohm

Max. Output Level

+20 dBu (balanced)

Output Ranges Balanced

20/14/8/2 dBu Unbalanced: 14/8/2 dBu

D to A Conversion

24 bit, 128 x oversampling bitstream

D to A Delay

0.63 ms / 0.68 ms @ 48 kHz / 44.1 kHz

Dynamic Range

104 dB typ, 20 Hz to 20 kHz

THD

typ <-94 dB (0.002 %) @ 1 kHz, +20 dBu Output

Frequency Response

+0/-0.5 dB @ 48 kHz, 20 Hz to 20 kHz <-100 dB, 20 Hz to 20 kHz

EMC
Complies with

EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B Formats: S/PDIF (24 bit), EIAJ CP-340, IEC 958

Safety Certified to

IEC 65, EN 60065, UL6500 and CSA E60065 CSA FILE #LR108093

Environment
Operating Temperature

32° F to 122° F (0° C to 50° C)

Storage Temperature

-22° F to 167° F (-30° C to 70° C)

Humidity

Max. 90 % non-condensing

Control Interface
MIDI In/Out/Thru

5 Pin DIN

Pedal

1/4" phone jack

General
Finish

Anodized aluminum front. Plated and painted steel chassis

Display

23 character / 280 icon STN-LCD display

Dimensions

19" x 1.75" x 8.2" (483 x 44 x 195 mm)

Weight

4.1 lb. (1.85 kg)

Mains Voltage

100 to 240 VAC, 50 to 60 Hz (auto-select)

Power Consumption

<15 W
