Features
- Ultra-low noise, high headroom field recorder and mixer with wireless remote control
- 4 Midas microphone preamps with phantom power and dual- stage A/D converters for 142 dB dynamic range 10 channels recording to SD cards and to the USB class- compliant interface with 32-bit float or 24-bit fixed point
- No analog gain setting required due to the dual-stage conversion, float recordings allow gain adjustment in post-processing
- Full-featured 8-channel mixer with level, pan, low-cut, tone, high-cut and dynamics
- Up to 8 channels of automixing with smooth gain-sharing algorithm
- Pre-record buffer for always capturing that "golden moment"
- StageConnect multi-channel uncompressed audio transmission at sub-millisecond latency using standard XLR/DMX cable
- Optional StageConnect FLOW 4VIO offers remote power, 4 additional microphone inputs, 2 headphone outputs
- SPMTE timecode can be generated internally for synchronizing other devices
- Aux Stereo Input, can also receive SMPTE clock to synchronize the internal clock
- Bluetooth audio can be received from mobile devices for Talkback or Playback
- Camera video CEC signal can be received via HDMI for triggering the audio recording
- Powered via StageConnect or via USB-C, power adaptor included
- 1/4-20 integrated thread and screw attaches to camera and tripods, with integrated Allen wrench
- FLOW 4V MIX app for iOS and Android offers remote control from mobile devices via Bluetooth LE
Technical Specifications
1 x 1/8" TRS jack, stereo
Max Output Level
110 mW @ 30Ω 110 mW @ 75Ω 75 mW @ 300Ω
Max Input Level
+24 dBu
Type
Micro HDMI
Channel Number
79
Channel at Host
12 IN/ 2 OUT
Dynamic Range (Inputs)
140 dB (142 dB A-weighted)
Type
4 x XLR/ 1/4" TRS combo jacks, balanced
EIN (20 Hz - 20 kHz)
-130 dBu (-132 dBu A-weighted)
Crosstalk rejection @ 1kHz, adjacent channels
-110 dB
Impedance
10 kΩ
Gain
1.84 dBi
Sample Rate
48 kHz
Phantom Power
+48 V, switchable
Dimensions (H x W x D)
53 mm x 184 mm x 128 mm
Frequency Range (± 1 dB)
5 Hz - 22 kHz
Weight
800g
Max Output Level (30 Ω load)
See HEADSET
Impedance
XLR: 9.5 kΩ bal. TRS: 30 kΩ bal.
Type
USB 2.0
Max Output Power
9.6 dBm
Connector
Type C
Version
Bluetooth 4.0 Dual Mode
Bit Depth
24-bit / 32-bit float
Frame Rate (FPS)
29.98, 24, 25, 30, 50, 60
Type
1 x 1/8" TRRS jack, stereo + mic in
Connector
USB-C
Impedance
40 Ω
Power Consumption
10 W
Distortion (THD + N, 30 Ω load)
See HEADSET
Compatibility
Supports A2DP 1.2 profile
Max Input Level
+10 dBu
Type
See HEADSET
Frequency range
2402 MHz ~ 2480 MHz
Max Communication Range
12 m (without interference)
Distortion (THD + N)
0.008% @ + 6 dBu in
Max Gain
+70 dB
CEC
Camera Controlled Rec Start
Max Input Level
XLR: +18 dBu TRS: +29.5 dBu
Power Supply / Voltage
USB-C PD
Distortion (THD + N)
0.007% @ -40 dBu in 0.0003% @ -20 dBu in
Max Output Level
+4.6 dBu
Impedance
100 Ω
